Standard Block Hand Plane with Adjustable Mouth
HomeStore

Standard Block Hand Plane with Adjustable Mouth

Standard Block Hand Plane with Adjustable Mouth

$114.99
Standard Block Hand Plane with Adjustable Mouth
$114.99

The Story

The WoodRiver® Block Plane is based on the venerable Stanley #65 low angle and #18 standard angle “Knuckle Cap” design, generally considered one of best block plane designs around. With the widely recognized comfortable chrome plated Knuckle Cap, these block planes look like the standard and low angle versions of yester year. Upon closer inspection you’ll notice changes to the base castings which not only strengthen historically weak points of the original design but also improve the blade bedding area. Improved blade adjustment mechanisms allow for crisp, easy adjustment of the blades using the rear adjustment knob. The adjustable mouth is very smooth to operate and allows fine tuning of the mouth for work ranging from coarse to creating whisper thin shavings. The stress relieved ductile iron castings are precision machined, flat and square. Each plane is outfitted with a high carbon tool steel tool blade, which is hardened to Rc60-64 for maximum edge retention and ground to a 25° bevel. We recommend sharpening the blades prior to use, however they’re impressively sharp right out of the box.

Features:


  • Ideal for trimming and adjusting miters, joinery and fitting doors and drawers
  • Based On A Classic Design
  • Knuckle Style Lever Cap
  • Soles and sides are machined flat and square within tightly held tolerances
  • Tools require minimal tune-up prior to use

Specifications:

  • Plane Dimensions (W x L): 2" x 7"
  • Blade Dimensions (W x T: 1-5/8" x 0.125"
  • Blade Material: High carbon tool steel
  • Blade Hardness: Rc 60-64
  • Blade Angle: 25°
  • Bed Angle: 20°

What's Included:

  • (1) WoodRiver Standard Block Hand Plane with Adjustable Mouth

Notes:

  • Get A FREE 3-Month Subscription to Rob Cosman's All-in-One Workshop! Learn fine woodworking in a Rob Cosman online workshop free for three months with purchase of a high quality WoodRiver® Hand Plane – Over $100 Value!
  • Workshop access and sign-up instructions are included with your purchase.

Standard Block Hand Plane with Adjustable Mouth - Image 2

Details & Craftsmanship

Every detail has been carefully considered to bring you the perfect product.

Standard Block Hand Plane with Adjustable Mouth - Image 3

Details & Craftsmanship

Every detail has been carefully considered to bring you the perfect product.

Standard Block Hand Plane with Adjustable Mouth - Image 4

Details & Craftsmanship

Every detail has been carefully considered to bring you the perfect product.

Standard Block Hand Plane with Adjustable Mouth - Image 5

Details & Craftsmanship

Every detail has been carefully considered to bring you the perfect product.

Standard Block Hand Plane with Adjustable Mouth - Image 6

Details & Craftsmanship

Every detail has been carefully considered to bring you the perfect product.

Standard Block Hand Plane with Adjustable Mouth - Image 7

Details & Craftsmanship

Every detail has been carefully considered to bring you the perfect product.

Standard Block Hand Plane with Adjustable Mouth - Image 8

Details & Craftsmanship

Every detail has been carefully considered to bring you the perfect product.

Description

The WoodRiver® Block Plane is based on the venerable Stanley #65 low angle and #18 standard angle “Knuckle Cap” design, generally considered one of best block plane designs around. With the widely recognized comfortable chrome plated Knuckle Cap, these block planes look like the standard and low angle versions of yester year. Upon closer inspection you’ll notice changes to the base castings which not only strengthen historically weak points of the original design but also improve the blade bedding area. Improved blade adjustment mechanisms allow for crisp, easy adjustment of the blades using the rear adjustment knob. The adjustable mouth is very smooth to operate and allows fine tuning of the mouth for work ranging from coarse to creating whisper thin shavings. The stress relieved ductile iron castings are precision machined, flat and square. Each plane is outfitted with a high carbon tool steel tool blade, which is hardened to Rc60-64 for maximum edge retention and ground to a 25° bevel. We recommend sharpening the blades prior to use, however they’re impressively sharp right out of the box.

Features:


  • Ideal for trimming and adjusting miters, joinery and fitting doors and drawers
  • Based On A Classic Design
  • Knuckle Style Lever Cap
  • Soles and sides are machined flat and square within tightly held tolerances
  • Tools require minimal tune-up prior to use

Specifications:

  • Plane Dimensions (W x L): 2" x 7"
  • Blade Dimensions (W x T: 1-5/8" x 0.125"
  • Blade Material: High carbon tool steel
  • Blade Hardness: Rc 60-64
  • Blade Angle: 25°
  • Bed Angle: 20°

What's Included:

  • (1) WoodRiver Standard Block Hand Plane with Adjustable Mouth

Notes:

  • Get A FREE 3-Month Subscription to Rob Cosman's All-in-One Workshop! Learn fine woodworking in a Rob Cosman online workshop free for three months with purchase of a high quality WoodRiver® Hand Plane – Over $100 Value!
  • Workshop access and sign-up instructions are included with your purchase.
